Description
John Deere Original Equipment Ball Stud – M164509
Part Specifications:
Ball Diameter (MM) 10.0000
Stud/Thread Diameter (MM) 8.0000
Series/Pitch (ALPHA) 1.2500
Stud Length (ALPHA) 20.0000
Size (MM) 12.8000
Flange Diameter (MM) 0.0000
Ball Height (MM) 14.5000
Material (ALPHA) JDS145
Style (ALPHA) 2
Finish (ALPHA) W-Clack Oxide
Note (A) There is more information on the engineering blue print that is not shown in detail here.
Fits the following John Deere models:
Utility Vehicle: HPX615E, HPX815E, XUV845E, XUV845M, XUV845R, XUV875M, XUV875R, XUV550, XUV550 S4, XUV560, XUV560 S4, XUV560E, XUV560E S4, XUV590E, XUV590E S4, XUV590i, XUV590i S4, XUV590M, XUV590M S4, XUV825M S4, XUV835E, XUV835M, XUV832R, XUV855 S4, XUV865E, XUV865M, XUV865R.
This is an O.E.M. John Deere part.
